Git 9: Extra material

The following extra material contains some more advanced things you can do with Git and the command line in general, which is not part of the main course materials. All the essential skills of Git are covered by the previous sections; the material here should be considered tips and tricks from people who use Git every day. You thus don’t need to use these things unless you want to, and you can even skip this part of the lesson if you like!

If you are interested in learning more about Git in general, here are some reading tips for you:

• Git cheat-sheet Links to an external site.
• A simple Git guide Links to an external site.
• Resources to learn Git Links to an external site.
• Git reference manual Links to an external site.

Forking

When you want to work on an Open Source project that is available on e.g. GitHub, you usually don’t have permission to directly push code to the project’s repository - this is so that the project’s maintainers are the only ones that can directly change anything in their codebase. How do you then contribute to projects that don’t allow you to push your code to their repository? Simple: use forking!

Forking is when you make your own copy of a repository on your GitHub account, which you will then have permissions to change as you see fit. You can then create pull requests from your fork to the original repository, rather than pushing code to a new branch and making a pull request from that. Working with forks just adds an additional step to the whole workflow: instead of being “clone; code and commit changes on a new branch; push branch to remote; pull request from branch” it becomes “fork; clone; code and commit changes; push code to fork; pull request from fork”.

You might also want to do a fork of a project simply because you want to have your own copy of it as well, without ever having the intention of changing it. This is, of course, perfectly fine as well, but do keep in mind that developers are usually quite happy to incorporate new changes from contributors if they are reasonable and fulfil a purpose and add functionality to the project. It is quite common that you have a use-case the maintainer didn’t think of before, and that you’ve helped the project grow by contributing your code!

Amending commits

Once in a while you’ll have just committed something to your Git repo and immediately remembered that you forgot to add something small, or perhaps you saw an error somewhere. While you can certainly just add that and make a new commit, wouldn’t it be nicer if you could just make the change as if it was already a part of the first commit? Well, you can! Just make the change, stage it and the commit together with the --amend flag, like so:

git add <file>
git commit --amend

This will add the staged changes to the previous commit as if they had always been there. Be careful, though! This will actually rewrite history, meaning that it only works if you only amended local changes. If you had already pushed the first commit to a remote repository you would run into trouble: you will be able to make the amend without issue, but you’ll get an error when you try to push your new changes, since the remote already contains the first version of the commit and can’t simply rewrite what it already has.

Amending changes is thus a good way to fix small mistakes you realise you made just after committing them, as long as you only amend local changes!

Rebasing

The git rebase command is an alternative to git merge in that it solves the same problem: getting changes in one branch into another branch. We’ve already gone through merging extensively, so how is rebasing different? Let’s look at a common case: a feature-branch which we want to get into the main branch.

Recall that a merge creates a merge commit, something akin to Merge branch 'feature-branch' into main or similar. This is a new commit that didn’t exist that brings the changes on feature-branch into main, but it contains no actual work itself. This is both a good and a bad thing: good, because merging is a safe, non-destructive operation (it doesn’t alter history); bad, because it can make the history itself look quite messy. These are the commands used and what the history will look like afterwards:

git checkout main
git merge feature-branch

(The commit with the dashed border is the merge commit.)

Rebasing, on the other hand does not create merge commits. Indeed, what rebase does is to “re-base” one branch on the other, i.e. pretend that new changes were done on a different base than what actually happened (hence the name). Getting our feature-branch onto main using rebase actually entails two separate steps: first the rebase itself, followed by a fast-forward merge:

git checkout feature-branch
git rebase main

This step rebases our feature-branch on top of main, meaning that we pretend that the commits on feature-branch were done based on the latest commits on main - you can also think of it as moving the entire feature-branch to the tip of the main branch. The commits with the dashed borders here indicate brand new commits; rebasing can’t somehow move the commits to the new base, rather it has to “replay” those commits as if they were done on the new base.

git checkout master
git merge feature-branch

We’ve now got our feature-branch commits onto main with a single, linear history without any merge commits! We did have to rewrite history, though, when we did the rebase itself. As with amending (see above), this is fine if we’re only working locally, but we’ll quickly run into trouble if we try to rebase things that have already been pushed. We can rebase on top of remote things, of course, since we’re not changing any remote history, only the local history. Be careful when you rebase!

Rebasing as clean-up

If the above section felt scary, don’t worry! There’s another highly useful use-case for git rebase that doesn’t risk destroying any history, namely local clean-up!

Let’s imagine you’ve worked on your local feature-branch for some time, and you have a number of commits on it. Some are highly related to each other and might actually be better suited as a single commit. You’ve also spotted a spelling error in one commit message, and realised that you missed important information in another. We can actually solve all of these issues with an interactive rebase! If you have 4 commits on your branch you can type the following:

git rebase -i HEAD~4

The -i flag means interactive, while HEAD~4 means 4 commits back from HEAD. This will open your default text editor and give you a selection looking something like this:

pick 0abf162 First feature commit
pick befc682 A minor change on the first commit
pick c9d1426 A commit with an uncomplete commit message
pick 2e0cb97 A commit with a spelling mitake

# Rebase 879ddcc..0abf162 onto 879ddcc (4 commands)
#
# Commands:
# p, pick <commit> = use commit
# r, reword <commit> = use commit, but edit the commit message
# e, edit <commit> = use commit, but stop for amending
# s, squash <commit> = use commit, but meld into previous commit

(... more instructions ...)

The commits are ordered with the most recent one at the bottom. The commented instructions (all of which are not shown here) show you what alternatives you have to work with; all you have to do is to change the pick keyword next to the commit hashes to whatever keyword you need from the list, save and exit.

In order to solve the toy example here we might decide that the four keywords should be pick, squash, reword and reword, from top to bottom. Once that’s done simply save and exit, and another instance of your default text editor will open for you to complete the specified changes. In the case above we’d get two separate new instances where we can change the commit message - these work the same as any normal commit.

Interactive rebasing is thus well-suited for fixing and cleaning of local changes you have yet to push anywhere, even if you don’t use rebasing as an alternative to merging! This can make your Git history both cleaner and more concise, which is great when you’re collaborating with others.

The reflog

We have shown many ways to work with Git and its various commands, and it occasionally happens that errors are introduced - especially when you’re not careful with using git commit --amend or git rebase on remote changes. This is where the reflog comes in. Think of the reflog as Git’s “safety net”: it stores almost every change you make to a Git repository (regardless of whether you commit the change) in a chronological manner. The following is an example of what the output of the git reflog command might show:

58deba6 HEAD@{0}: merge: feature-branch: Fast-forward
8c80c88 HEAD@{1}: checkout: moving from feature-branch to main
555544a HEAD@{2}: commit: feature development 2
4c92630 HEAD@{3}: commit: feature development 1
8c80c88 HEAD@{4}: checkout: moving from main to feature-branch

It shows the most recent change at the top, notified by HEAD@{0}. We thus have a merging of feature-branch into main, a checkout into main, two commits on feature-branch and a checkout into feature-branch - reading it backwards we get a chronological log of what has happened.

The reflog is incredibly useful for when you’ve lost something you later realise you want to access again, such as when you’ve just used git reset. The reflog might look like this, for example:

bc3641f HEAD@{0}: reset: moving to HEAD~2
caf9321 HEAD@{1}: commit: More work on the feature
1bc36af HEAD@{2}: commit: Work on a new feature

We see two commits related to some new feature and a reset to HEAD~2 (two commits back from HEAD). If we realise that we actually liked the work we just threw away we can move around in the reflog in a similar manner we do normal commits:

git checkout HEAD@{1}

This will put us back to the state we were in before we used git reset. We here refer to the reflog using the HEAD@{N} notation, which differs from the usual HEAD~N notation so that it is clear if it is the commit history or the reflog that is intended. While the reflog is hopefully not something you’ll have to use often it’s quite useful to know it exists, if only to be able to search the internet for more details regarding a problem you’ve encountered!

Decorating your prompt

When you are working on the command line interface (CLI), you will usually have some small pieces of information relating to your current directory, the name of the computer or host you’re working on, and so forth. You’ve probably already seen your prompt while working with Git throughout this lesson, but here’s an example of what one might look like:

erikfmbp:~/teaching/workshop-reproducible-research erik.fasterius $

The above prompt contains the name of the computer, a colon, the current working directory, the username and a dollar-sign; it is stored in the variable PS1. You can type echo $PS1 to see what variables your prompt is made up of; the above example contains \h:\W \u\$, where \h is the hostname, \W the working directory and \u the username.

Note
If you’re using zsh instead of bash you’ll have to replace the backslashes (\) in the commands with percent signs (%).

Some people like to also show the current branch on their prompt, thus avoiding having to type git branch continuously. There are several ways you might do this, and we’re only presenting one of them here: a bash function.

git_branch() {
     git branch 2> /dev/null | sed -e '/^[^*]/d' -e 's/* \(.*\)/ (\1)/'
}

This function does a number of things:

1. Ejects the error message from Git if the current directory isn’t a part of a Git repository into /dev/null (i.e. into nothing).
2. Find the current branch by searching for a line that starts with * (i.e. the current branch) using the command line program sed.
3. Put the current branch into parentheses with a space before it.

We can then build our new prompt by adding this function into it:

# The first part of the old prompt
PS1='\h:\W \u'

# Add the Git branch
PS1=$PS1'$(git_branch)'

# Add the last part of the old prompt
PS1=$PS1' \$'

Now you should see the current Git branch on your prompt! The only problem now is that this only works for your current session: once you restart your CLI you’ll have to re-define your prompt again. This can be circumvented, though. What you need to do is to add the code defining your prompt into your so-called bash profile: ~/.bash_profile. Every time you load a new CLI session this file is read and any code inside it is executed. You might already have this file, so make sure you don’t overwrite it!

Bash aliases for git

Some Git commands are used over and over again when working with git, such as git status. Some people like to have aliases (i.e. shortcuts) for these common commands. Here is a small list of such aliases that you may find useful or, even better, might inspire you to create your own! Add them to your ~/.bash_profile as above, so that they’re available across sessions.

# Basic git commands
alias gb='git branch'
alias ga='git add'
alias gd='git diff'
alias gcm='git commit'
alias gp='git push'
alias gu='git pull'
alias gm='git merge'
alias gco='git checkout'
alias gl='git log'

# Git status in short format
alias gst='git status -s'

# Add and commit all tracked and modified files
alias gca='git commit -a'

# Create and checkout a new branch
alias gcob='git checkout -b'

# Git log with one line per commit
alias glo='git log --oneline'

Pretty logs

If you want to customise e.g. the format and the colours of the logs you can use the gitconfig file (the same one we added things to using git config --global user.name "Mona Lisa" in the pre-course setup). You can read more about exactly what you can do at the documentation for Git configs Links to an external site. and pretty formats Links to an external site., but we’ll provide two examples here:

[format]
    pretty = format:%C(yellow)commit %H %C(auto)%d %nAuthor: %C(cyan)%aN %C(italic reset)(%ae) %nDate:   %C(blue)%ar %C(italic reset)(%ai) %n%n%C(bold reset)%w(0,6,6)%s%n%C(reset)%+b

This first example alters the format of the default git log command. It looks similar to what you’d be used to seeing with that command, except his has some colour highlights and adds the relative date (e.g. “1 hour ago” and similar relative times).

[pretty]
    line = format:%C(yellow)%h %C(blue)%>(12)%ar %C(cyan)%aN%C(auto)%d %C(reset)%s

This second example is a custom format that can be called using git log --pretty=<format-name>, and is similar to the built-in --oneline flag, but also containing nicer colours, the relative date as well as the author name ;the format name line here is used for its similarity to oneline. You can add any number of custom formats you like using such config specifications. If you’re using aliases as in the section above you might change the glo alias to be git log --pretty=line instead, which will give you the nicer log on one line.
